PVIM-1 ESP32 AD7606 Precision Voltage IoT Monitor Board
PVIM, ESP32 AD7606 Precision Voltage IoT Monitor Board designed for Electronics Hobbyist, Electronics Labs and Home Automation
Description
PVIM, ESP32 AD7606 Precision Voltage IoT Monitor Board designed for Electronics Hobbyist, Electronics Labs and Home Automation
New board for August 2023
This SDK Board is a Precision, Eight Channel, Synchronous Data Acquisition board (DVM), with Simultaneously Sampled Isolated Inputs. This board is provided fully tested.
Self-contained Data Acquisition SDK. 16-bit 200 kHz Analog to Digital Conversion. AD7606 ADC Sampling into an onboard ESP32.
PVIM board options include either an internal Wi-Fi/BT antenna (on the ESP32), or External Antenna (via U.FL). The default is the ESP32-WROOM-32E, with PCB antenna.
PVIM ESP32 AD7606 SDK 1.2304.101 Beta PCA – Components
The PVIM board is suppled fully tested. You will require to flash your specific code, or from our examples on GitHub
Solder configuration pads are provided on the bottom.
In the Box
PVIM AD7606 ESP32 board.
You will need to update the firmware with your preferred open source firmware, using a standard micro USB cable (not included). Working examples of test code can be found in our Wiki and GitHub
- 1 x PVIM-1 ESP32 Board
- SMD (Surface Mounted Components) Populated.
- Fully Tested
- 8 x 5mm Terminal Blocks (2 Pin – Not Soldered)
- 1 x Strip of straight pin header
- 1 x 4 pin header socket (Not Soldered)
