The ESPuno Pi Zero, is a pin compatible Raspberry Pi ESP32 Controller and Emulator in a single board.

The Raspberry Pi GPIO’s are controlled and driven from the ESP32-C6 and GPIO Expander, so bringing Raspberry Pi PiHat’s and Breakout boards to the Arduino Embedded controller world.

Top Level Devices

The purpose of ESPuno Pi Zero, is to provide a very compact board which includes the below main features:

Espressif ESP32-C6
- WiFi, Bluetooth, Zigbee and Thread
PCA9671
- 16 Port GPIO Expander. 5V Tolerant.
TI TMP102 -Digital Temperature
Siproin SSP9481 -5 to 60V DC SMPS for wide ranging power input, providing a stable 5V
OnSemi NCP167BMX330 -5V to 3V3 DC SMPS
EEPROM P24C64C -64Kbit storage -Two of these are included, one for ATGM336H and one for the ESP32-C6.

Video

Where can ESPuno Pi Zero be used?

The ESPuno Pi Zero board can be used in a wide range of projects and installations such as:

Agriculture
Automation
Commercial
Drones
Factories
Farms
Greenhouses
Homes
Industry
Makers
Modelling
Off Grid Systems
Robotics
Scientific Research
Security
Shipping
Smart systems
Solar Farms
STEM Education
Surveillance
Wind Farms

Variants

Two variants of the ESPuno Pi Zero are available. Essentially, this is with either an internal PCB antenna, or with a U.FL connector for external antenna.

ESPuno Pi Zero ESP32-C6-1
ESPuno Pi Zero ESP32-C6-1U (IPEX MHF3)

This product is the ESPuno Pi Zero ESP32-C6-1U (IPEX MHF3)

Important Antenna U.FL IPEX MHF3 Information

Features

Radio and U.FL

ESPRanger main MCU is the ESP32-C6 which includes a powerful radio module, opening up a range of IoT applications that include:

Wi-Fi 6

2.4 GHz (2400 ~ 2483.5 MHz)
802.11ax (20 MHz bandwidth)
802.11b/g/n (20/40 MHz bandwidth)
CE Max EIRP 19.81 dBm

Bluetooth

2.4 GHz (2400 ~ 2483.5 MHz)
Bluetooth LE
Bluetooth 5.3
Bluetooth Mesh
CE Max EIRP 18.46 dBm

Thread 1.4

2.4 GHz (2405 ~ 2480 MHz)
802.15.4
Thread Mesh
CE Max EIRP 10.29 dBm

Zigbee 3.0

2.4 GHz (2405 ~ 2480 MHz)
802.15.4
Zigbee Mesh
CE Max EIRP 10.40 dBm

Zigbee and mesh are expanding in an range of home, farming and industrial applications, so will be interested to see how this develops over time.

Using a mix of Ethernet and Zigbee, installations could offer remote mesh systems, with a mix of communications technologies.

ESPuno Pi Zero – Overview

ESPuno Pi Zero – Espressif ESP32-C6
- ESP32-C6-MINI
- Wi-Fi 6 2.4 GHz 802.11ax | 802.11b/g/n
- Bluetooth | LE | 5.3 | Mesh
- Thread 1.4 | 802.15.4 | Mesh
- Zigbee 3.0 | 802.15.4 | Mesh
Power from up to 60V DC
- Wide range of Input DC Voltages 5V to 60V
Compact mechanical Pi Zero form
- Only 65 mm * 30 mm
Powered from:
- USB C (5V)
- External 5-60V DC
  - Battery
  - Solar Panels
RS-485 Interface
- Industry Standard MODBUS
- DMX Lighting Controller Interface
PCA9671 GPIO Expander
- Pi Header Inputs and Outputs
TMP102 Digital Temperature Sensor
Voltage Regulators
- 5V SMPS 600mA
- 3V3 LDO 700mA
GROVE Ecosystem
- Standardised I2C Expansion Interface
ADC Inputs
- ESP32-C6 12-bit
PWM Output
- ESP32-C6
24C64 EEPROM
- 64Kbit (8192 x 8)
- On-board Data Logging and User Parameters
UART Integrated Type C ‘ESP32-C6 DEV’ Interface
RTC On-Board 32.768 kHz XTAL for ESP32-C6 Real Time Clock
RGB Status User Programmable LED
Tactile Buttons Reset and PGM / User
